Fume Removal Rate Commercial Kitchen Electrostatic Precipitator for Air Extractor DGRH-K-21000
Commercial kitchen electrostatic precipitator, Commercial kitchen esp, electrostatic precipitator, electrostatic air filter, electrostatic air cleaner, electrostatic air purifier, ecology unit, ESP, ESP COLLECTOR
Do you need one air pollution control system for commercial kitchen exhaust, such as grease, smoke, oil mist etc? These contaminants can be filtered efficiently to meet local air quality environmental protection standards by RUIHE ESP system. Our ESP is a high and low voltage high efficiency air filtration unit. RUIHE ESP has various air collection methods utilized to recover contaminants
Specification
Fume Removal Rate Commercial Kitchen Electrostatic Precipitator for Air Extractor DGRH-K-21000 Specifications
| No. | Model | Air Flow (M³/H) | Cabinet Size L*W*H (MM) | Flange Size (W*H) | Removal efficiency Rate | Wind Resistance (PA) | Power(Watt) | Net Wight(KG) | Remark |
|---|---|---|---|---|---|---|---|---|---|
| 1 | DGRH-K-21000 | 18000-21000 | 640*1835*1460 | 1560*1260 | 90-93% | <100 | 840 | 244 | W/O UV-C tube, single pass |
| 2 | DGRH-K-21000U | 18000-21000 | 640*1835*1460 | 1560*1260 | 90-93% | <100 | 2040 | 258 | W/ 8*UV-C tube,single pass |
Advantage
- Dirty air is double pass. Up to 90-93% Smoke, grease particles removal efficiency rate
- Modular in design: Easy installation, maintenance and cleaning.
- Cost effective & eco-friendly: Long life-span, minimum maintenance energy-saving and space-saving.
- Durable aluminum plate type collector cells. Saving 60-70% power than honeycomb models in the market.
- Durable stainles steel blade ionizers prevent common tungsten wire breakage and replacement.
- Intellegent electrostatic power control system: Electric intensity auto-control function ensures the unit maintains a high purification rate after a long time service.
- Safety and Stability: (1) Door-open power-off protection, (2) Over-current, voltage & temperature protection
- Optional: Photolysis and odour removal efficiently with UV-C filter systems.
- Optional: Photolysis and odour removal efficiently with UV-C filter systems.
